B650 PRO RS AM5 4DDR5 HDMI M.2 DP USB3.2 ATX

193,99 €

Monthly payment starting from 6,61 €

Open installments calculator

Photopoint hire purchase calculator

Please add some items to your shopping cart and choose "hire purchase" for the payment type

Main info

Add to cart

Delivery in 7-10 working days

Free delivery

14 14 days return policy when purchasing online

Built for the Most Advanced PCs

  • AM5 Changes Everything
  • AMD EXPO Technology

Optimised VRM design

  • Dr. MOS incorporates the latest SPS (Smart Power Stage) technology. It monitors the voltage and temperature of each phase ensuring the right amount of power is delivered to the processor for enhanced performance and overclocking capabilities.
  • Robust components and smooth power transfer to the CPU translate into enhanced performance for gamers.

8-Layer PCB Design

The 8-layer PCB provides stable signal paths and power shapes for lower temperatures and higher power efficiency, ensuring reliable operation and top performance without compromise.

Extreme Overclocking Performance

  • DDR5 EXPO and XMP support
  • Starting from the concept of designing build for stability and reliability, ASRock does not compromise on any details. All B650 motherboards are built with an 8-layer PCB design, so enthusiasts can enjoy enhanced DDR5 memory overclocking performance of up to 6400 MHz and beyond by using pre-tested profiles. Ensure memory modules support AMD EXPO/Intel XMP and overclocking can be affordable, rewarding and effortless.
  • Blazing OC Tuner
  • The Blazing OC Tuner allows the AM5 processor to switch between OC mode and PBO (Precision Boost Overdrive) mode when the CPU voltage reaches the required threshold. Anything above the current threshold will trigger manual OC mode; if it is below the current threshold, Precision Boost Overdrive mode will be activated. The idea is to combine overclocking on all cores and automatically boosting power on one core to get the best CPU performance. There is no need for configuration from the BIOS, all settings can be modified in the operating system in real time.

DDR5 memory with protection circuitry

Due to the unique electrical architecture of the DDR5 DIMM, there is a high risk of damaging the memory module if the AC power is not properly disconnected during removal or installation. To prevent this, ASRock has implemented a seamless protection circuit on each DDR5 motherboard, reducing the risk of memory module damage.

Nahimic Audio

  • Audio That Matters
  • Whether you use headphones, speakerphone, external or internal speakers via USB, Wi-Fi, analogue output or HDMI, Nahimic Audio offers the best audio experience, vivid and full of detail.
  • Improved Communication Quality
  • Powerful algorithms for the best noise-free conversation, ensuring consistent voice levels regardless of the distance from the microphone. The Nahimic audio engine dynamically cleans the sound, removes noise and reduces voice variability. The result is better understanding and less fatigue.
  • - Static suppression
  • - Echo cancellation
  • - Side sound reduction
  • - Voice stabilisation
  • Best Gaming Experience
  • -Sound Tracker
  • Sound Tracker is a visual indicator that shows the directions from which the dominant sounds are coming. Each sound is appropriately positioned on a 360° radar to ensure full immersion into the game.
  • -Works on all devices!
  • Enjoy vivid and high quality surround sound on all your favourite audio devices: jack, USB, Bluetooth, HDMI, S/PDIF. Nahimic is compatible with all your favourite audio tools and delivers the best sound with each of them. Nahimic measures and improves to optimise our technology and provide the best experience.

POLYCHROMATIC RGB

In addition to the built-in RGB backlighting, the board also features integrated, regular and addressable RGB headers that allow the connection of compatible LED devices such as LED strips, CPU fans, fans, cases, etc. Users can synchronise RGB LED devices with the certified Polychrome RGB Sync accessories to create their own unique backlighting style.

High Speed M.2 Solution

  • PCIe Gen5 Blazing M.2
  • This motherboard is ready to accept a host of M.2 devices, including support for PCI Express 4.0 M.2 SSDs, ready to operate at twice the speed of the previous 3rd generation, delivering lightning fast data transfer rates.
  • XXL M.2 heatsink
  • An extra-large aluminium alloy M.2 heatsink effectively improves heat dissipation to keep high-speed M.2 SSDs as cool as possible. Provides better stability while maintaining top performance.

USB3.2 Gen2 Gen2 Type-C

The latest USB 3.2 Gen2x2 Type-C enables data transfer speeds of up to 20 Gbps, 2x faster than the previous generation. The lightning-fast interface also features a reversible USB Type-C design, so you can connect your device either side.

EZ Settings

  • Automatic Driver Installation
  • No need to worry about missing drivers! The ASRock board comes with the LAN driver pre-installed, offering you a convenient option to install the rest of the drivers.
  • Step1: Install Auto Driver Installer
  • Step2: Update your drivers
  • Step3: Done!
  • BIOS Flashback
  • Update the BIOS with a simple click. Users can easily upload the latest BIOS with a USB stick and power supply. No processor, RAM or other components are needed for this.
  • Flexible integrated I/O port bezel
  • Unlike most pre-installed bezels, which are merely decorated with a colour scheme, our port cover can be adjusted during installation, guaranteeing a perfect fit to the case without any technical problems.

Model B650 PRO RS
CPU socket Socket AM5
Processor family AMD Ryzen 7
Processor family AMD Ryzen
Processor family AMD Ryzen 5
Processor family AMD Ryzen 9
Integrated CPU No
Chipset manufacturer AMD
Chipset type AMD B650
Memory type DDR5
Number of DDR5 slots 4
Memory bus frequency 6200 MHz
Max memory size 128
Expansion slots 1 x M.2
Expansion slots 1 x PCIe 4.0 x 1
Expansion slots 1 x PCIe 4.0 x 16
Expansion slots 1 x PCIe 3.0 x 16
Max. number of SATA devices 2
RAID Yes
Graphics AMD RDNA 2 integrated graphics card (Support may vary by CPU) 1 x HDMI TMDS/FRL 1 and 2 with 8G, supports HDR, HDCP 2.3 max. Resolution up to 4K 120Hz 1 x DisplayPort 1.4 with DSC (Compressed), supports HDCP 2.3 and max. Resolution up to 4K 120Hz
Sound card 7.1 CH HD Audio (Realtek ALC897 Audio Codec) Nahimic Audio
Network interface 1 x 10/100/1000/2500 Mbit/s
USB ports at back panel 10
USB ports on motherboard 6
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 4
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 3
FireWire (IEEE 1394) No
COM connector / port No
LPT connector / port No
External connectors 1 x Flash BIOS Button
External connectors 1 x HDMI
External connectors 1 x Line In
External connectors 1 x Line Out
External connectors 1 x MIC
External connectors 1 x RJ-45
External connectors 6 x USB 2.0
External connectors 2 x USB 3.0
External connectors 1 x USB 3.1
External connectors 1 x USB 3.1 Type-C
External connectors 2 x SMA
External connectors 1 x DisplayPort
Onboard connectors 1 x USB C
Onboard connectors 1 x Thunderbolt header
Onboard connectors 1 x 4pin 12V power
Onboard connectors 1 x 8pin 12V power
Onboard connectors 1 x 24pin ATX zasilanie
Onboard connectors 2 x USB 2.0/1.1 header
Onboard connectors 1 x USB 3.0 header
Onboard connectors 1 x 4pin CPU fan
Onboard connectors 4 x 4pin Chassis fan
Onboard connectors 1 x 4-pin water-pump-fan
Onboard connectors 1 x TPM header
Onboard connectors 1 x Front panel audio header
BIOS 256Mb AMI UEFI Legal BIOS with GUI support
Form factor ATX
Dimensions 30.5 x 24.4 cm
Accessories included User manual 2 x SATA data cables 3 x screws for M.2 sockets
Supported operating systems Windows 11
Supported operating systems Windows 10
Software ASRock Motherboard Utility (A-Tuning) ASRock Dragon 2.5G LAN Software ASRock Polychrome SYNC* *Te narzędzia można pobrać z Live Update & APP Shop.
Other information Certifications: FCC, CE ErP/EuP compliant (ErP/EuP compliant power supply required)
Detailed data on disk/drive interfaces PROCESSOR: 1 x Blazing M.2 slot (M2_1, Key M), supports 2280 PCIe Gen5x4 mode (128 Gbps)*. Chipset: 1 x M.2 slot (M2_2, Key M), supports 2242/2260/2280 SATA3 6.0 Gbps and PCIe Gen3x2 (16 Gbps)* modes. 1 x Hyper M.2 slot (M2_3, Key M), supports 2260/2280 P
Network interface 2.5 Gigabit LAN 10/100/1000/2500 Mbps Dragon RTL8125BG Supports Dragon 2.5G LAN Software Intelligent automatic bandwidth adjustment Visual user-friendly interface Visual network usage statistics Optimised default settings for game, browser and streaming m

Dimensions and weights

Gross weight
2.1 kg
Package width
38.5 cm
Package height
32 cm
Package length
9.5 cm

Product codes

EAN
4710483940750
Manufacturer code
KBASRAA8B650A02
