Home page » Computers & IT»Computer components»CPUs»Intel Core i7-14700K processor 33 MB Smart Cache Box

Intel Core i7-14700K processor 33 MB Smart Cache Box

Main info

Product has been archived


Processor operating modes 64-bit
Maximum number of PCI Express lanes 20
Embedded options available No
Processor cache 33 MB
Tjunction 100 °C
Memory channels Dual-channel
On-board graphics card DirectX version 12.0
Discrete graphics card model Not available
Intel® Turbo Boost Technology 2.0
Intel® Secure Key Yes
Stepping B0
Discrete graphics card No
PCI Express configurations 2x8+1x4
Number of execution units 32
Intel® Clear Video HD Technology (Intel® CVT HD) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Processor package size 45 x 37.5 mm
Thermal Monitoring Technologies Yes
Intel® OS Guard Yes
Processor codename Raptor Lake
Processor family Intel® Core™ i7
Non-ECC Yes
ECC Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Processor cache type Smart Cache
Maximum internal memory 192 GB
Processor threads 28
On-board graphics card Yes
Enhanced Intel SpeedStep Technology Yes
Processor cores 20
On-board graphics card model Intel UHD Graphics 770
Processor model i7-14700K
Intel® Quick Sync Video Technology Yes
CPU configuration (max) 1
Memory bandwidth (max) 89.6 GB/s
Processor socket LGA 1700
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Virtualization Technology (VT-x) Yes
Processor manufacturer Intel
Status Launched
Market segment Desktop
Maximum turbo power 253 W
Maximum internal memory supported by processor 192 GB
Processor base power 125 W
Scalability 1S
On-board graphics card OpenGL version 4.5
Idle States Yes
Processor ARK ID 236783
Maximum number of DMI lanes 8
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz
Execute Disable Bit Yes
On-board graphics card ID 0xA780
Intel® Control-flow Enforcement Technology (CET) Yes
Thermal solution specification PCG 2020A
Intel® Boot Guard Yes
Intel® Turbo Boost Max Technology 3.0 frequency 5.6 GHz
Box Yes
L2 cache 28672 KB
Harmonized System (HS) code 8542310001
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels
Cooler included No
Export Control Classification Number (ECCN) 5A992C
On-board graphics card base frequency 300 MHz
Intel® Volume Management Device (VMD) Yes
Memory bandwidth supported by processor (max) 89.6 GB/s
Efficient cores 12
Mode-based Execute Control (MBE) Yes
Intel® Speed Shift Technology Yes
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1
Intel Turbo Boost Max Technology 3.0 Yes
OpenCL version 3.0
On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz
On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels
On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels
On-board graphics card dynamic frequency (max) 1600 MHz
Performance-core boost frequency 5.5 GHz
Launch date Q4'23
Number of displays supported (on-board graphics) 4
Intel® Thread Director Yes
Use conditions Workstation
On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Intel 64 Yes
Performance cores 8
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Standard Manageability (ISM) Yes
Direct Media Interface (DMI) Revision 4.0
Multi-Format Codec Engines 2
Processor generation Intel® Core™ i7 (14th gen)
Warranty 36 (G)
Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
Performance-core base frequency 3.4 GHz
PCI Express slots version 4.0
Memory types supported by processor DDR5-SDRAM
On-board graphics card outputs supported DisplayPort 1.4a
Supported instruction sets SSE4.1
Warnings Ensure that the processor is adequately cooled to prevent overheating.

Dimensions and weights

Package width
120 cm
Package height
100 cm
Package length
50 cm

Product codes

EAN
5032037278485
Manufacturer code
BX8071514700K
