Home page » Computers & IT»Computer components»PSU»Chieftec EON 500W ATX Retail 80 PLUS W

Chieftec EON 500W ATX Retail 80 PLUS W

Main info

Product has been archived


Warranty 24 (G)
PCI Express power connectors (6+2 pin) 1
Combined power (-12V) 4.8 W
Depth 140 mm
Max output current (+3.3V) 20 A
Peripheral (Molex) power connectors (4-pin) 2
Motherboard power cable length 65 cm
Max output current (-12V) 0.4 A
Number of SATA power connectors 4
Max output current (+5Vsb) 2.5 A
AC input voltage 200 - 240 V
Combined power (+5Vsb) 12.5 W
Cooling type Active
Combined power (+5V) 100 W
Power supply unit (PSU) form factor ATX
Total power 500 W
EPS power connector (4+4 pin) Yes
Product colour Black
Input current 3.5 A
Max output current (+5V) 20 A
Power factor 0.9
AC input frequency 50 Hz
80 PLUS certification 80 PLUS
ATX power connector (20+4 pin) Yes
Weight 1.2 kg
Combined power (+12V) 444 W
Width 150 mm
Motherboard power connector 20+4 pin ATX
ATX version 2.3
Fan diameter 12 cm
Cabling type Non-Modular
Supported motherboard form factors ATX
Purpose PC/server
On/off switch Yes
CPU power connector (4+4 pin) Yes
Package type Box
Max output current (+12V1) 37 A
Combined power (+3.3V) 100 W
Height 86 mm
Power Factor Correction (PFC) type Active
Warranty period 2 year(s)
Package weight 1.45 kg
Sustainability certificates ErP
Compliance certificates EAC
Peripheral (Molex) power cable length 450 mm
Power protection features Short circuit
SATA power cable length 450
Hazard pictogram(s) GHS07: Harmful
Warnings Do not open the case - risk of electric shock.

Dimensions and weights

Package width
185 cm
Package height
257 cm
Package length
103 cm

Product codes

EAN
0753263078612
Manufacturer code
ZPU-500S
