IP CAMERA HIKVISION DS-2CD2666G2HT-IZS(2.8-12mm)

Main info

Product has been archived


Warranty 24 (F)
Type IP security camera
Height 95.7 mm
Ethernet LAN Yes
Angle of rotation 360°
Power source type DC, PoE
Ethernet interface type Fast Ethernet
Product colour White
Weight 1.52 kg
LED type IR
Power consumption (max) 14.5 W
Number of cameras 1
Quality of Service (QoS) support Yes
Bit rate 32 Kbps - 16 Mbps
Operating temperature (T-T) -30 - 60 °C
IK code IK10
Connectivity technology Wired
Package depth 190 mm
Highlight Compensation (HLC) Yes
Length 298 mm
Ethernet LAN (RJ-45) ports 1
Back Light Compensation (BLC) Yes
Operating relative humidity (H-H) 0 - 95%
Frame rate 30 fps
Wide Dynamic Range (WDR) Yes
Width 97.9 mm
Night vision distance 60 m
Storage relative humidity (H-H) 0 - 95%
Reset button Yes
Minimum illumination 0 lx
Camera shutter speed 1/3 - 1/100000 s
Audio output channels 1.0 channels
Package weight 2.53 kg
Tilt angle range 0 - 90°
Package height 180 mm
International Protection (IP) code IP67
Form factor Bullet
Audio input channels 1.0 channels
Alarm output channels 1
Optical sensor size 25.4 / 1.8 mm (1 / 1.8")
Storage temperature (T-T) -30 - 60 °C
Alarm input channels 1
Bluetooth No
Pan range 0 - 355°
Package width 385 mm
Housing material Metal
Web-based management Yes
Wi-Fi No
Networking standards IEEE 802.3af
Signal-to-Noise Ratio (SNR) 52 dB
Total megapixels 4 MP
Maximum resolution 3200 x 1800 pixels
Card reader integrated Yes
Digital watermark Yes
Observe distance (tele) 72.8 m
Number of lenses 1
Detect distance (tele) 183.3 m
Alarm input/output Yes
Video motion detection Yes
Privacy masking Yes
Progressive scan Yes
Region of Interest (ROI) encoding Yes
Live view Yes
Lens viewing angle, vertical 58.1 - 23.1°
Recognize distance (wide) 14.9 m
Noise reduction technology 3D noise reduction
Sensor type CMOS
Maximum aperture number 1
Power consumption (Power over Ethernet (PoE)) 18 W
DC output voltage 12
Mirror Yes
Password reset via email Yes
Mounting type Ceiling/wall
Privacy protection Yes
Infra-red wavelength 850 nm
Smart IR Yes
Active tampering alarm Yes
Night vision Yes
Terminal block port Yes
Video streaming Yes
DC output current 1.21 A
Day/night mode Yes
Client interoperability iVMS-4200, Hik-Connect, Hik-Central
Number of simultaneous live view channels 6 channels
Alert notification type E-mail
Maximum memory card size 512 GB
Video recording Yes
Heartbeat Yes
Password protection Yes
Number of users 32 user(s)
Placement supported Outdoor
User access level Administrator, Operator, User
Noise reduction Yes
IP address filtering Yes
Number of sensors 1
Detect distance (wide) 74.3 m
HTTPS encryption Yes
Focal length range 2.8 - 12 mm
Observe distance (wide) 29.5 m
Built-in HDD No
Languages support Multi
Bit rate control Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Sample rates 8 - 48 kHz
Behavior analysis Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
Digest authentication Yes
Identify distance (tele) 18.3 m
Recognize distance (tele) 36.7 m
Dynamic range 120 dB
Infrared (IR) cut-off filter Yes
Number of languages 33
Human and vehicle targets classification Yes
Lens viewing angle, diagonal 137.4 - 47.3°
Pixel counter Yes
Identify distance (wide) 7.4 m
Bit rate range 8 - 320 Kbit/s
Lens viewing angle, horizontal 112.3 - 41.2°
Audit log Yes
Automatic Network Replenishment (ANR) Yes
Network access storage (NAS) Yes
Number of Privacy masking areas 4
Compatible memory cards MicroSDXC
Video compression formats H.265
Image quality adjustment Brightness
Security algorithms EAP-MD5
Protection features Vandal proof
Warnings Ensure that the product is properly installed and protected against falling.
Intelligent Video Surveillance (IVS) system features Scene change
Supported graphics resolutions 1280 x 720 (HD 720)
Audio formats supported G.711
Compliance certificates CE

Camera

Horizontal swivel
360°

Dimensions and weights

Package width
245 cm
Package height
330 cm
Package length
145 cm

Product codes

EAN
6942160480411
Manufacturer code
52580
